Specification:
| 1 | Available Currency | As per your requirement |
|---|---|---|
| 2 | Counting Speed | 720-800pcs/min |
| 3 | Hopper Capacity | 1200pcs |
| 4 | Number of Pocket | 1 hopper, 4 stackers, 2 rejecting pockets |
| 5 | Stacker Capacity | 500pcs |
| 5 | Rejecting Bill Capacity | 150pcs |
| 6 | Image-Scanning-as Recognition Technology | Adopted double Sides high-speed image scanner Gray scale of image: 256 level Optical definition: 200dpi |
| 7 | PC intertace | USB2.0, RS-232 serial port |
| 8 | Rated Voltage | 220V(±10%) or as required |
| 9 | Frequency | 50Hz(±5%) |
| 10 | Power | ≤450W |
| 11 | RiSing temperature | ≤20℃ |
| 12 | Appearance DimenSion | 600x440x600(mm) |
| 13 | Weight | 80kgs |
Features :
- Adopted the cutting-edge CIS, DSP technology. Identification and control system use FPGA+DSP structure, more CPU in procesSing.
- Auto detect counterfeit banknote by uSing Light Image, IR Image, Spectrum Image, Magnetic Image, UV, Magnetic Ink, Thread Metal, IR Penetration, Multipoint Thickness Measurement etc. Error code indicated and alarm sound when find fake banknote.
- Detect incomplete, damaged, holes, fold, pen marks, oil, overlapped, spliced, tape and double on the banknote.
- Separate the suspected notes from damaged notes, easy to organize notes, reduce the workload
- Have many functions, such as counting, verSion sorting, orientation sorting, sorting banknote for ATM machine, adding, batching, serial number checking and output, connecting LAN etc
- Adjustable senSitivity, auto storage, self checking after being switched and displaying the error code, restorable to defacult setting
- Super LCD display, attachable to portable-type LED display
- Software upgrading via internet or U disk.
